Radiance – Opal 1’X4′ Flatpanels
Wattage: 28W | 36W
Installation: In false ceiling : Suitable for Armstrong/ POP/Gypsum board ceiling by replacing the board through luminaire
In True Ceiling : Surface mounting through screws
- Elegant epoxy coated CRCA MS housing with milky opal diffuser
- Robust and stylish design
- High luminous efficacy & low power consumption
- Glare free uniform light distribution
- More than 65% energy savings compared to conventional luminaires
- Excellent color rendering index for perceiving great visual experience
- Mounting : Recess | Surface
- Available in cool white, neutral white & warm white CCT
Application
PRODUCT DRAWING
TECHNICAL SPECIFICATIONS
| WATTAGE | RATED VOLTAGE | LUMEN EFFICACY | THD | PF | CRI | DIMENSION (mm) | ||
|---|---|---|---|---|---|---|---|---|
| A | B | C | ||||||
| 30W | 220-240 VAC,50Hz | >100lm/W | <10% | >0.95 | >80 | 595 | 595 | 70 |
| 36W | 220-240 VAC,50Hz | >100lm/W | <10% | >0.95 | >80 | 595 | 595 | 70 |
| 48W | 220-240 VAC,50Hz | >100lm/W | <10% | >0.95 | >80 | 595 | 595 | 70 |
Dimension tolerance:- ± 5mm
